Mixer ULM-164/SW | IMG STAGELINE | 6-kanals

H202240A
0141934f03

Mixer ULM-164/SW | IMG STAGELINE | 6-kanals

1.875,00 kr. Inkl. moms

Direkte fra fjernlager
2-4 dage
Z

Dansk Webshop

Z

14 dages fuld returret

Z

Nem betaling

Z

Professionel rådgivning

Mange betalingsmuligheder

Universal line mixer, 6 channels.

  • 6 stereo inputs/mono inputs
  • 2 stereo outputs, independent of each other (master 1 via RCA and 6.3 mm jack), 1 mono output
  • 3-way equalizer
  • LED VU meter, switchable for both outputs
  • Clip LED for each channel
  • Balance controls with centre click for the stereo input channels
  • Extended muting function
  • Adjustable headphone output
  • 482 mm (19″) rack installation, 1 RS
Varenummer (SKU): 202240
Mærke: IMG Stageline EAN: 4007754182781 Kategori:

Specifikationer og beskrivelse

No. of channels 6
No. of inputs 12
Mic input -
Line input 150 mV/50 kΩ (stereo), 6 x RCA L/R
150 mV/25 kΩ (mono), 6 x 6.3 mm jack, unbal.
CD input -
Phono input -
Tape (play) -
Aux input -
Insert input -
effect return -
Master output 1 V/600 Ω (stereo), 2 x RCA (1 x 6.3 mm) L/R
2 V/600 Ω (mono), 1 x 6.3 mm jack
Record output -
Monitor output -
Booth output -
Aux output -
Insert output -
effect send -
Control room -
Tape (rec) -
Headphones ≥8 Ω, 1 x 6.3 mm jack
Gooseneck lamp -
WiFi
USB -
Frequency range 20-20,000 Hz
THD 0.05%
S/N ratio 69 dB, unweighted
Crosstalk -
Equalizer bass ±12 dB/80 Hz
Equalizer midrange ±12 dB/1 kHz
Equalizer treble ±12 dB/10 kHz
equalizer -
Talkover -
Phantom power -
Crossfader -
Media player -
Amplifier -
Power supply ˜ 230 V/50 Hz/10 VA
Mains voltage ˜ 230 V
Mains frequency 50 Hz
Power consumption, operation 10 VA
Alternative operating voltage -
Alternative power supply -
Admiss. ambient temp. 0-40 °C
Dimensions 482 x 48 x 175 mm, 1 RS
Width 482 mm
Height 48 mm
Depth 175 mm
Rack spaces, RS 1
Weight 2.3 kg
